Product Overview & Application Scenarios
Product Overview
The HM3200 Insulator Conductivity Salt Density Tester is a precision instrument designed for contamination flashover prevention in power systems. It measures the Equivalent Salt Deposit Density (ESDD), solution conductivity, and temperature on insulator surfaces. Its core function is to provide critical data for pollution level classification and contamination zone mapping, ensuring proper selection of external insulation creepage distances for power transmission equipment, thereby enhancing grid safety.
Application Scenarios
Power Systems: Pollution monitoring and maintenance of insulators in substations and transmission lines.
Research & Education: Anti - flashover studies and experimental data analysis for power equipment.
Industrial Fields: Insulation performance evaluation in high - pollution environments (e.g., chemical, metallurgical industries).
Emergency Testing: Rapid salt density measurement and pollution level assessment in field or complex environments.
Key Features & Advantages
High Precision: Salt density resolution of 0.0001 mg/cm², full - scale accuracy ±2%, with automatic temperature compensation for reliable data.
Efficiency & Convenience: Auto - ranging, single measurement in 2.5 seconds; built - in 100,000 - group storage, supports USB export or direct printing.
Smart Functions:
(1) Auto - elimination of background salt interference, reducing requirements for cleaning solutions.
(2) Automatic switching between live/dead - line measurement modes for complex conditions.
User - Friendly Design:
4.8-inch color touch screen, Chinese and English interface free switching.
2600mAh built - in battery for extended field operation.
Multi - Function Integration: Directly displays and outputs salt density, conductivity, temperature, pollution level, and unified creepage distance for rapid decision - making.
Operating Conditions
Environment: 0°C–60°C, humidity <90% RH; avoid strong electromagnetic interference.
Test Objects: Suitable for porcelain, glass, and composite insulator surface salt density detection.
Power Maintenance: Regular charging recommended; battery maintenance advised at 5°C–35°C.
Additional Information
Compliance Standards:
(1) GB/T16434 - 1996, GB/T16434 - 200X (pollution environment insulation standards).
(2) Q/GDW152 - 2006 (power industry pollution classification standards).
Data Management: Supports single - record review, deletion, batch export, and printer compatibility.
Extended Functions: Auto - generates pollution level reports and assists in contamination zone mapping.
Maintenance & FAQs
Conclusion The HM3200 Insulator Conductivity Salt Density Tester, with its high precision, intelligent design, and portability, is the optimal solution for contamination flashover prevention in power systems. It delivers robust technical support for ensuring safe and stable grid operations.
Optimized for SEO: Keywords include "insulator salt density tester," "ESDD measurement," "conductivity analyzer," and "grid safety tools."
Hot Tags: insulator conductivity salt density tester, China insulator conductivity salt density tester manufacturers, factory, Variable Frequency Power Supply, Primary Current Injection Test Set Box type, hv testing equipment, electrical safety inspection equipment, ac/dc electrical safety inspection instrument, primary current injection tester
Technical Specifications
|
Parameter |
Specification |
|
Measurement Range |
Salt Density: 0.0001–9.9999 mg/cm² (based on X - 4.5 insulator) |
|
Temperature: 0°C–100°C; Conductivity: 0–200,000 μS/cm |
|
|
Basic Error |
Salt Density Resolution: 0.0001 mg/cm²; Full - Scale Accuracy: ±2% |
|
Temperature Resolution: 0.1°C, Accuracy ±0.5°C; Conductivity Resolution: 0.01 μS/cm |
|
|
Environmental Conditions |
Operating Temperature: 0°C–60°C; Humidity: <90% RH |
|
Physical Properties |
Dimensions: 356mm × 260mm × 133mm; Weight: ~2.5kg |
|
Power Supply |
Built - in 2600mAh lithium battery, ideal for prolonged field use. |
