Product Overview & Applications
Product Overview
The Insulating Oil Kinematic Viscosity Tester is an automated testing device compliant with the national standard GB/T 265-1988. This instrument is specifically designed to determine the kinematic viscosity of petroleum liquids (Newtonian fluids). It calculates the kinematic viscosity value by timing the flow of the sample through a calibrated glass capillary under constant temperature conditions and combining this with the capillary constant. It can also measure dynamic viscosity in conjunction with density data, meeting the precise testing requirements of the petrochemical industry.
Application Areas
Petrochemical Laboratories: Quality testing of crude oil, lubricants, fuel oils, and other products.
Quality Inspection Agencies: Conducting viscosity compliance testing according to national or industry standards.
R&D Centers: Evaluating viscosity performance during the development of new materials or additives.
Production Monitoring: Real-time viscosity stability monitoring of liquid products on production lines.
Technical Specifications
|
Parameter |
Specification |
|
Display |
Color LCD display and touch screen |
|
Temperature Range |
Ambient to 150°C |
|
Set temperature |
20℃,40℃,50℃,80℃,100℃,any value(Higher than room temperature~150℃) |
| Temperature control accuracy | ±0.1℃ |
| Number of test holes |
4 |
|
Timing Range |
0~999 second (According to the national standard, the flow time of each test sample must be higher than 200 seconds.) |
|
Timing Accuracy |
0.1 second |
|
Timing number |
1~4 times (Optional) |
| Printing method | Panel mounted thermal printer |
|
Power Supply |
AC220V±5%, 50Hz±5% |
|
Power Consumption |
1600W |
| Ambient humidity | 10%~80% |
| Ambient temperature | 5℃~35℃ |
| Volume | 45cm×34cm×42cm |
| Weight | 15kg |
