HMXZ-400kVA/60kV Inductance-Adjustable Series Resonance Withstand Voltage Test Set
- Excitation Transformer JLB-40kVA/6kV/0.4kV (Dry-type)
- Resonance Control Panel CZT-40kVA/380V (with protection function)
- Adjustable Reactor DK(L)-400kVA/60kV (Oil-filled, inductance 7H–12H, Q ≥ 10)
- Voltage Divider FRC-60kV (Voltage Division Ratio 1000:1, Accuracy Class 1.5)
- Test Connection Box, Factory Test Report, User Manual, Certificate of Conformity, and Warranty Card
FAQs
Q: What is the capacitance range of test specimens compatible with this device?
A: The compatible capacitance range for test specimens is 1.06–1.272 μF, corresponding to an adjustable inductance range of 7 H–12 H for the reactor.
Q: What is the device's own quality factor (Q)?
A: The overall quality factor (Q) of the device is ≥10; the adjustable reactor has a Q ≥ 10; the additional DK-60kVA/30kV reactor has a Q ≥ 30 (f = 45 Hz).
Q:What is the maximum temperature rise after 5 minutes of operation?
A: The temperature rise is ≤65 K.
